HWT-D3222-10-SIU

მარაგშია

1 TOPS computing power
Supports behavior analysis, crowd flow analysis, target detection, person detection, object (motor vehicle, non-motorized vehicle, and pedestrian) classification, vehicle recognition, vehicle event detection, and traffic flow statistics
Supports backlight adaptation and overcast adaptation
1/2.7″ CMOS sensor
120 dB super wide dynamic range (WDR), ensuring that both foreground and background objects are clearly identified in environments with sharp light contrast
Supports PoE power supply

აღწერა

Image sensor	1/2.7″ CMOS/2MP 1920 (H) x 1080 (V)
Min illumination	Color: 0.002 lux (F1.6, AGC ON); B/W: 0.001 lux (F1.6, AGC ON) or 0 lux (infrared illuminator enabled)
Day/Night mode	Supported; automatic (ICR)/Color/B/W (default: automatic); Sensitivity level: high (default), medium, and low. Image triggering/Internal triggering
White balance	Auto/Manual/OnePush
Digital noise reduction	2D/3D noise reduction
WDR	120 dB
HLC/BLC	Supported/Supported
EIS	Supported; Sensitivity levels are not supported
Optical Defogging/Algorithm-assisted Defogging	Supported
Signal-to-Noise Ratio(SNR)	> 45 dB
Power type	12 V DC and PoE (IEEE 802.3af)
Power consumption	Maximum: 10 W; typical: 3.5 W
Operating temperature	–30°C to +60°C
Operating humidity	5% to 95% (non-condensing)
Surge protection	4 kV
IP rating	IP67
Corrosion resistance	Class C corrosion resistance
IK rating	IK10
Weight	Net weight: 0.95 kg; gross weight: 1 kg
Dimensions	Device dimensions: φ127 mm x 97 mm; package dimensions: 112 mm x 147 mm x 147 mm
Alarm port	2 input ports and 1 output port
Audio port	Supported (one-channel LINE IN and one-channel built-in MIC)/Supported (one-channel LINEOUT)
