OSX010000

OSX010000 Specification

Transceiver form factor

SFP+

Transmission speed

10 Gbit/s

Center wavelength (nm)

1310

Standard compliance

10Gbase-LR

Connector type

LC

Applicable cable and maximum transmission distance

Single-mode fiber: 10 km

Transmit power (dBm)

-8.2 to +0.5

Maximum receiver sensitivity (dBm)

-12.6

Overload power (dBm)

0.5

Extinction ratio (dB)

3.5

Operating temperature

0°C to 70°C (32°F to 158°F)

Net Dimension(D x W x H mm)

110 x 70 x 37
