CXP-100G-SR10

CXP-100G-SR10

$10,837.00 Original price was: $10,837.00.$2,498.00Current price is: $2,498.00.
მარაგშია
Model:CXP-100G-SR10= – Cisco 100 Gigabit Optical Modules
Detail:CXP-100G-SR10 Transceiver module Spare
მარაგშია
  • Day and night customer service
Category:

აღწერა

The Cisco® CXP 100GBASE modules offer clients a wide assortment of high-thickness 100Gbps availability answers for short-arrive at server farm organizing, superior processing organizations, undertaking center collection, and specialist co-op transport applications.

Main Features

100 Gigabit Ethernet

100GBase-SR10

MPO multi-mode

850 nm

CXP-100G-SR10= Specification

Description100GBASE-SR10 CXP Module for MMF compliant to 10GBASE-SR
Dimensions13.3 x 24 x 62 mm (0.52 x 0.94 x 2.44 in)

CXP Port Cabling Specifications

Wavelength (nm)850
Cable TypeMMF
Core Size (Microns)50.0

50.0

Modal Bandwidth (MHz*km)***2000 (OM3)

4700 (OM4)

Cable Distance*100m

150m**

* Minimum cabling distance for -LR4 modules is 2m, according to the IEEE 802.3ba.

** Considered an engineered link with maximum 1dB allocated to connectors and splice loss.

*** Specified at transmission wavelength.

Optical Transmit and Receive Specifications

Type100GBASE-SR10

10GBASE-SR

Transmit Power (dBm)*Max:-1.0 per lane

Min:-7.6 per lane

Receive Power (dBm)*Max:2.4 per lane

Min:-9.5 per lane

Transmit and Receive Center Wavelength Range (nm)12 lanes:

840 to 860 nm

* Transmitter and receiver power are in averages, unless specified.

Environmental Conditions and Power Requirements

Storage temperature-40 to 185°F (-40 to 85° C)
CXP operating temperature 0 to 70°C (32 to 158°F)
CXP power consumptionAt 70°C: <3.5W maximum
