CPAK-100G-PSM4

CPAK-100G-PSM4

$22,000.00
მარაგშია
Model:CPAK-100G-PSM4= – Cisco 100 Gigabit Optical Modules
Detail:CPAK optical transceiver module, PSM4 500m SMF, parallel
მარაგშია
  • Day and night customer service
Category:

აღწერა

This Cisco Optics Modules QSFP-100G-PSM4-S viable QSFP28 handset gives 100GBase-PSM4 throughput up to 500m over single-mode fiber (SMF) utilizing a frequency of 1310nm by means of a MPO connector. It is destined to be 100% viable with the same Cisco handset. This simple to introduce, hot-swappable handset has been customized, interestingly serialized and information traffic and application tried to guarantee that it will instate and perform indistinguishably. Computerized optical observing (DOM) uphold is additionally present to permit admittance to constant working boundaries. This handset is Trade Agreements Act (TAA) consistent.

Main Features

100G-PSM4-S)

100 Gigabit Ethernet

100GBase-PSM4

MPO single-mode

up to 1640 ft

1310 nm

TAA Compliant

Related Products

CPAK-100G-PSM4= Specification

Description100GBASE PSM4 Cisco CPAK Module for SMF
Dimensions11.6 x 34.8 x 101.2 mm (0.46 x 1.37 x 3.98 in)

Cisco CPAK port cabling specifications

Wavelength (nm)1295 to 1325
Cable TypeSMF (12 fibers)
Core Size (Microns)9-micron core SMF per G.652
Modal Bandwidth (MHz*km)
Cable Distance500 m

Optical transmit and receive specifications

Type100GBASE PSM4 SMF
Transmit PowerMax:+2.0 per lane

Min:-9.4 per lane

Receive Power (dBm)Max:+9.4 per lane

Min:-2.0 per lane

Transmit and Receive Center Wavelength Range (nm)Four lanes: 1295 to 1325
Supported Mode1x100G
Supported ProtocolIEEE 802.3ba

Environmental conditions and power requirements

Storage temperature -40 to 85° C (-40 to 185° F)
Operating temperature 0 to 70° C (32 to 158° F)
Power consumption At 70° C: <9.0W maximum
