Cisco NIM-2T – 2 port synchronous serial WAN network interface module, Smart Serial, 8 Mbps
2 port synchronous serial WAN network interface module, Smart Serial, 8 Mbps. Used to keep legacy synchronous serial WAN circuits on a modular branch router during migration.
- Day and night customer service
Description
Cisco NIM-2T: 2 port synchronous serial WAN network interface module, Smart Serial, 8 Mbps, from the Cisco 4000 Series ISR Serial Network Interface Modules. Used to keep legacy synchronous serial WAN circuits on a modular branch router during migration. Supplied new and genuine by Green Code Technologies.
Key features
- Two synchronous serial ports at up to 8 Mbps each
- Cisco Smart Serial connectors, same cabling as HWIC-2A/S and HWIC-4A/S
- EIA-232, EIA-449, EIA-530, EIA-530A, V.35 and X.21 serial standards
- HDLC, PPP and Frame Relay WAN protocols
Specifications
| Part number | NIM-2T |
|---|---|
| Module type | Synchronous serial WAN network interface module |
| Ports | 2 |
| Interfaces | Cisco Smart Serial connectors |
| Serial standards | EIA-232, EIA-449, EIA-530, EIA-530A, V.35, X.21 |
| Max speed | Up to 8 Mbps per port |
| Supported platforms | Cisco 4451-X (max 3); Catalyst 8300 Series |
| Slot type | NIM slot, no slot restrictions |
| Form factor | Single-wide NIM |
| Dimensions | 1.25 x 3.50 x 7.24 in (3.18 x 8.89 x 18.39 cm) |
| Operating temperature | 0 to 40C (32 to 104F) |
| Minimum software | Cisco IOS XE 3.12 with IP Base |
Specifications are taken from the Cisco datasheet and may vary by software release and licence.
Browse more: Cisco Router Network Interface Modules · Cisco Modules & Cards.
Request a quote: send us the part number and quantity and we will reply with price, lead time and delivery options to the UK, the Gulf, Africa and the Caucasus.
