AP5030DN-C

AP5030DN-C Specifications

Technical

Dimensions (H × W × D)

8.7 in. x 8.7 in. x 2.1 in. (220 mm x 220 mm x 53 mm)

Weight

0.8 Kg

Power

Power input

DC 12V ± 10%

PoE Power: -48V DC

PoE function in compliance with IEEE 802.3af and 802.3at

Maximum power consumption

12.95W

Note: Actual maximum power consumption depends on local laws and regulations.

Environment

Operating temperature

14oF to 122oF (-10°C to 50°C)

Storage temperature

-40oF to 158oF (-40°C to 70°C)

Humidity

5% to 95% (Non-condensing)

Waterproof grade

IP41

Radio specifications

Antenna Type

Built-in

Antenna Gain

2.4G: 4 dBi
5G: 5 dBi

Maximum Number of Concurrent Users

≤ 256

Maximum Transmit Power

2.4G：25dBm

5G：25dBm
