EG8040F

EG8040F Specification

Dimensions (H x W x D)
(mm)

176 mm x 138.5 mm x 28 mm

Operating temperature

0°C to +40°C

Operating humidity

5% RH to 95% RH (non-condensing)

Power adapter input

100–240 V AC, 50/60 Hz

System power supply

11–14 V DC, 0.5 A

Static power consumption

4 W (V3R015C10 and before)
3.5 W (after V3R015C10)

Maximum power consumption

5.5 W (V3R015C10 and before)

4 W (after V3R015C10)

Ports

4FE

Indicators

POWER/PON/LOS/LAN
