817753-B21
In Stock
| Model: | 817753-B21 – Networking Adapters for HPE Server |
| Detail: | HPE Ethernet 10/25Gb 2-port 640SFP28 Adapter |
- Day and night customer service
Description
817753-B21 Specification | |
| Capacity | |
| Type | Jumbo frame size |
| Value | Up to 9.6 KB |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 5 – 95% (non-condensing) |
| Header | |
| Compatibility | PC, Unix |
| Manufacturer | Hewlett-Packard |
| Packaged Quantity | 1 |
| Product Line | HPE |
| Model | 640SFP28 |
| Brand | HPE |
| Interface Provided | |
| Qty | 2 |
| Connector Type | SFP28 |
| Type | 25Gb Ethernet |
| Miscellaneous | |
| Compliant Standards | ACA, BSMI Class A, CISPR 22 Class A, cTUVus, EN 55022 Class A, EN 60950-1, EN55024, FCC Class A certified, ICES-003, RoHS 6/6, VCCI Class A |
| Networking | |
| Type | Network adapter |
| Form Factor | Plug-in card |
| Connectivity Technology | Wired |
| Data Transfer Rate | 25 Gbps |
| Data Link Protocol | 10 Gigabit Ethernet, 25 Gigabit Ethernet |
| Remote Management Protocol | SNMP |
| Compliant Standards | IEEE 1588v2, IEEE 802.1ab (LLDP), IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1Qbg, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3az, IEEE 802.3x |
| Status Indicators | Link/activity |
| Features | Extended Message-Signaled Interrupts (MSI-X), Full duplex mode, IPv4 support, IPv6 support, Jumbo Frames support, LACP support, Large Send Offload (LSO), LLDP support, Network Virtualization using Generic Routing Encapsulation (NVGRE), PXE support, QoS tagging, Quality of Service (QoS), RDMA over Converged Ethernet (RoCE), RDMA over Converged Ethernet (RoCE) v2, Receive Side Scaling (RSS), TCP Segmentation Offload (TSO), TCP/IP checksum offload, TCP/IP offloading, UDP/IP offloading, UEFI support, Virtual Extensible LAN (VXLAN), VLAN support |
| Interface Type | PCI Express 3.0 x8 / PCI Express 3.0 x4 |
| PCI Specification Revision | PCIe 3.0 |
| Low Profile | Low profile |
| Performance | |
| Type | Bidirectional throughput |
| Value | 100 Gbps |
| Ports | |
| Qty | 2 |
| Type | 25 Gigabit Ethernet |
| Power Device | |
| Power Consumption Operational | 9.7 Watt |
| Processor | |
| Type | Mellanox ConnectX-4 Lx |
| Installed Qty | 1 |
| Manufacturer | Mellanox Technologies |
| Service | |
| Support Details Type | Limited warranty |
| Support Details Full Contract Period | 1 year |
| Service & Support | |
| Type | 1 year warranty |
| System Requirements | |
| Min Operating System | Citrix XenServer 6.5, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Oracle Solaris 11.1, Red Hat Enterprise Linux 6.6, Red Hat Enterprise Linux 6.7, Red Hat Enterprise Linux 7, Red Hat Enterprise Linux 7.1, Red Hat Enterprise Linux 7.2, SuSE Linux Enterprise Server 11, SuSE Linux Enterprise Server 12, Ubuntu 14.04, VMware ESXi 5.5, VMware ESXi 6.0 |
