DS-2CC12D8T-AMM

DS-2CC12D8T-AMM Specification

Camera

Image Sensor

2MP CMOS Image Sensor

Signal System

PAL/NTSC

Effective Pixels

1920(H)*1080(V)

Shutter Time

1/25(1/30) s to 1/50,000 s

Lens Mount

C/CS Mount

Auto Iris

DC Drive

Day& Night

IR cut filter with auto switch

Wide Dynamic Range

120dB

Video Frame Rate

1080p@25fps/1080p@30fps

HD Video Output

1 Analog HD output

Synchronization

Internal Synchronization

CVBS Output

1Vp-p Composite Output(75Ω/BNC)

S/N Ratio

More than 62 dB

Up the Coax

Support

Menu

Camera ID

On/off (15 characters, position programmable)

D/N Mode

Auto / Color / B/W

Auto White Balance

Auto / Manual

Private Mask

ON/OFF, 4 programmable privacy masks

Motion Detection

On/Off, maximum 4 zones

BLC

On/Off

AGC

Support

Anti-flicker

On/ Off

Language

English/Chinese

General

Operating Conditions

-30 °C ~ 60 °C (-22 °F ~ 140 °F)

Humidity 90% or less (non-condensing)

Power Supply

12 VDC ±25%, 24 VAC ±25%

Communication

Up the coax

Protocol: HIKVISION-C(Coaxitron)

Dimension

69.29 mm × 54 mm × 56 mm (2.73″ × 2.13″ × 2.2″)
