C9500-12Q-E

$18,850.00 Original price was: $18,850.00.$4,659.00Current price is: $4,659.00.
მარაგშია
Model:C9500-12Q-E – Cisco Switch Catalyst 9500
Detail:Catalyst 9500 12-port 40G switch, Network Essentials, Need to order DNA License

PDF Attachment:

c9500-12q-e datasheet

cisco-catalyst-9400-switch-datasheet

guide-to-upgrade-cisco-access-and-backbone-switch

cisco new switch selection decision 2021-22

selecting-cisco-switches-campus-branch-digital-building



მარაგშია
  • Day and night customer service
Category:

აღწერა

c9500-12q-e datasheet, Buying Cisco C9500-12Q-E Switches for Gear Net Technologies will be a magnificent method to give your office organization, an increase in speed and execution that likewise at an extraordinarily low cost.

While constructing any sort of office, the most fundamental piece of gear you will require is Switch. Likewise, there is just one organization you will hear nowadays that produces a-list switches… and that is Cisco! Cisco produces switches for each area and necessity, from Cisco Switches for both Access and Compact Campus LAN Switches to Cisco Nexus Series switches for server farms.

The Cisco Catalyst 9500 Series Switches are the up and coming age of big business class center and collection layer switches, supporting full programmability and functionality. In light of an x86 CPU, the Catalyst C9500-12Q-E Series is Cisco’s lead reason fabricated fixed center and total venture exchanging stage, worked for security, IoT, and cloud. The Catalyst 9500 Series is the business’ first reason assembled 40 Gigabit Ethernet line of switches focused on the undertaking grounds.

We are having Cisco Switches for sale and you can get these switches at an affordable rate. Take advantage of this sale and book your product now! Also, have a look at other Cisco Products, Cisco switches like C9200-48P-E, WS-C2960S-F48LPS-L, C9500-12Q-E etc. For any kind of queries regarding the product and it’s purchase, you can contact sales@gntme.com

c9500-12q-e datasheet

C9500-12Q-E Specifications

Switching capacityUp to 480 Gbps full duplex
Forwarding rateUp to 720 Mpps
Total number of MAC addressesUp to 64,000*
Total number of IPv4 routes (Address Resolution Protocol [ARP] plus learned routes)Up to 64,000 indirect*

Up to 32,000 host*

Total number of IPv6 routesUp to 32,000 indirect*

Up to 16,000 host*

Multicast scaleUp to 48,000*
QoS ACL scaleUp to 18000*
Security ACL scaleUp to 18000*
FNF entriesUp to 512,000*
DRAM16 GB
Flash16 GB
VLAN IDs4000
Total Switched Virtual Interfaces (SVIs)4000
Jumbo frame9198 bytes
Dimensions (H x W x D)1.73 x 17.5 x 21.52 in
Rack units (RU)1 RU
Chassis with 2 power supplies and built-In fan25.75 lb (11.68 kg)
Input voltage90 to 264 VAC
Operating temperature32°F to 104°F (0° to 40°C)
Storage temperature-4° to 149°F (-20° to 65°C)
Relative humidity operating and nonoperating noncondensingAmbient (noncondensing) operating: 5% to 90%

Ambient (noncondensing) nonoperating and storage: 5% to 95%

AltitudeOperation up to 6000 ft
MTBF (hours)179,660

Power supply specifications

Power Supply FeatureSupport in the Catalyst 9500 Series
AC power max rating950W
System power consumption850W max
Input-voltage range and frequencyAC 115 to 230 VAC, 50 to 60 Hz
Power supply efficiency94%
Total output BTU (Note: 1000 BTU/hr = 293W)2901 BTU/hr (850W) max
Input currentAC 10A at 115VAC, 5 A at 230VAC
Output ratings12V at 79A, 12V at 3A
Output holdup timeAC = 10 ms at maximum load
Power-supply input receptaclesAC IEC 60320 C16
Power cord ratingAC 15A
