C9300-24S-A Datasheet

C9300-24S-A Datasheet

$21,390.00 Original price was: $21,390.00.$5,948.00Current price is: $5,948.00.
მარაგშია
Model:C9300-24S-A Datasheet – Cisco Switch Catalyst 9300
Detail:Catalyst 9300 24 GE SFP Ports, modular uplink Switch

PDF Attachment: c9300-24s-a-datasheet

მარაგშია
  • Day and night customer service
Category:

აღწერა

C9300-24S-A Datasheet – Cisco Switch Catalyst 9300

We the Gear Net Technologies are a Dubai-based company having 11 years of experience in distributing and supplying IT, networking, and security product and services across the globe. You don’t have to visit from one shop to another for purchasing the switch, you can order it to your doorstep just by purchasing a switch from our website. These network switches are built for security, IoT, and the cloud. With full PoE+ capability, power, and fan redundancy, stacking bandwidth up to 688 Gbps, modular uplinks,

The Cisco Catalyst 9300 Series Switches are Cisco’s lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. They are the next generation of the industry’s most widely deployed switching platform. The Catalyst 9300 Series switches form the foundational building block for Software-Defined Access (SD-Access), Cisco’s lead enterprise architecture. At 480 Gbps, they are the industry’s highest-density stacking bandwidth solution with the most flexible uplink architecture. The Catalyst 9300 Series is the first optimized platform for high-density 802.11ac Wave2. It sets new maximums for network scale. These switches are also ready for the future, with an x86 CPU architecture and more memory, enabling them to host containers and run third-party applications and scripts natively within the switch.

Check C9300-24S-A Datasheet price and buy Cisco Switch Catalyst 9300 with the best discount. We provide fast shipping and free CCIE support. you can also buy other products like C9300-24P-E, C9300-24T-A.

Main Features

  • Network Advantage
  • switch
  • L3
  • managed
  • 24 x Gigabit SFP
  • rack-mountable

C9300-24S-A Datasheet Specification

Product CodeC9300-24S-A
Product DescriptionCatalyst 9300 24 GE SFP Ports, modular uplink Switch
Total 10/100/1000 or Multigigabit copper ports24x 1G SFP
Uplink ConfigurationModular Uplinks
Default AC power supply715W AC
Available PoE powerN/A
Dimensions (H x W x D)1.73 x 17.5 x 17.7 Inches
Cisco StackWise-480Yes
Cisco StackPowerYes
Default power supplyPWR-C1-715WAC-P
Switching capacity208 Gbps
Stacking bandwidth688 Gbps
Forwarding rate154.76 Mpps
Total number of MAC addresses32,000
Total number of IPv4 routes (ARP plus learned routes)32,000 (24,000 direct routes and 8000 indirect routes)
IPv4 routing entries32,000
IPv6 routing entries16,000
Multicast routing scale8000
QoS scale entries5120
ACL scale entries5120
Packet buffer per SKU16 MB buffer for 24- or 48-port Gigabit Ethernet modelst

32 MB buffer for 24 and 48-port Multigigabit

FNF entries64,000 flow on 24- and 48-port Gigabit Ethernet models

128,000 flows on 24-port Multigigabit

DRAM8 GB
Flash16 GB
VLAN IDs4094
Total Switched Virtual Interfaces (SVIs)1000
Jumbo frames9198 bytes
Total routed ports Catalyst per 9300 Series stack448
Wireless bandwidth per switchUp to 96 Gbps on 48-port Gigabit Ethernet model
Mean time between failures – MTBF (hours)284,130
Safety certifications





•UL 60950-1

•CAN/CSA-C222.2 No. 60950-1

•EN 60950-1

•IEC 60950-1

•AS/NZS 60950.1

•IEEE 802.3

Electromagnetic emissions certifications•47 CFR Part 15

•CISPR22 Class A

•EN 300 386 V1.6.1

•EN 55022 Class A

•EN 55032 Class A

•CISPR 32 Class A

•EN61000-3-2

•EN61000-3-3

•ICES-003 Class A

•TCVN 7189 Class A

•V-3 Class A

•CISPR24

•EN 300 386

•EN55024

•TCVN 7317

• V-2/2015.04

•V-3/2015.04

•CNS13438

•KN32

•KN35

•IEC 61000-6-1

•EN 61000-6-1

EnvironmentalReduction of Hazardous Substances

(ROHS) 5
