| General |
| Device Type | Network adapter |
| Interface (Bus) Type | PCI Express 3.0 x16 Mezzanine |
| PCI Specification Revision | PCIe 3.0 |
| Networking |
| Ports | Infiniband EDR x 2 |
| Connectivity Technology | Wired |
| Data Link Protocol | InfiniBand |
| Data Transfer Rate | 100 Gbps |
| Features | PXE support, UEFI support, InfiniBand EDR Link support, Extended Reliable Connected transport (XRC), Dynamically Connected transport (DCT), user mode registration and remapping of memory (UMR), On demand paging (ODP) |
| Compliant Standards | IBTA 1.3 |
| Processor / Memory |
| Processor | 1 x Mellanox ConnectX-4 |
| Miscellaneous |
| Compliant Standards | EN55024, EN55022 Class A, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, IEC 60068-2-32, RoHS, FCC Part 15 A, IEC 60068-2-29, IEC 60068-2-64, CAN/CSA C22.2 No. 60950-1, KC, VCCI Class A, AS/NZS CISPR22:2006 Class A |
| Pricing Type | Factory integrated |
| Software / System Requirements |
| OS Required | SuSE Linux Enterprise Server 12 SP1, CentOS 7.2 (64-bit), Red Hat Enterprise Linux 7.2 (64-bit) |
| Manufacturer Warranty |
| Service & Support | Limited warranty – parts – 1 year |
| Compatibility Information |
| Designed For | HPE ProLiant XL230k Gen10 Compute Tray, XL260a Gen9, XL260a Gen9 Compute Tray |
