H801GPMD
In Stock
< tbody >
| Model: | H801GPMD – Huawei MA5603T(MSO) PON Board |
| Detail: | Huawei SmartAX MA5600T 8-port Advanced GPON OLT Interface Board |
- Day and night customer service
Description
H801GPMD Specification | |
| Forwarding capability | 20 Gbit/s |
| T-CONTs per PON port | 1024 |
| Service flows per PON board | 6144 |
| Maximum frame size | 2004 bytes |
| MAC addresses | 16384 |
| Maximum distance difference between two ONUs under the same PON port | 40 km from V800R013 |
| N:1/1:1 VMAC | Supported |
| FEC | Bidirection |
| CAR group | Supported |
| IPv6 | Supported |
| 4-level HQoS | Not supported |
| Variable-length OMCI | Supported from V800R013 |
| ONU-based shaping or queue-based shaping | Supported |
| Load sharing | Supported |
| High-precision clock and time synchronization | Supported |
| Type B (single-homing)/Type C protection | Supported |
| Rogue ONU detection and isolation | Supported |
| Automatic shutdown at high temperature | Supported |
| Automatic shutdown of an idle port | Supported |
| 1:64 eOTDR | Supported (used together with the reflector) |
Environment | |
| Operating temperature | -40° C to +65° C |
| Power consumption | • Static: 32 W • Maximum: 46 W |
