C1-C2960X-48TD-L

C1-C2960X-48TD-L

$5,825.00
In Stock



Model:C1-C2960X-48TD-L – Cisco ONE Catalyst 2960 Series Platform
Detail:Cisco ONE Catalyst 2960-X 48 GigE, 2 x 10G SFP+, LAN Ba

PDF Attachment: C1-C2960X-48TD-L Datasheet

In Stock
  • Day and night customer service
Category:

Description

Buying Cisco C1-C2960X-48TD-L Switches for Gear Net Technologies will be a magnificent method to give your office organization, an increase in speed and execution that likewise at an extraordinarily low cost.

Cisco Catalyst 2960-X arrangement switches are fixed-setup, stackable Gigabit Ethernet switches that give endeavor class admittance to grounds and branch applications. Intended for operational effortlessness to bring down the absolute expense of possession, they empower versatile, secure, and energy-productive business tasks with savvy administrations and the scope of cutting-edge Cisco IOS programming highlights.

The Cisco Catalyst 2960-X Series switches are fixed-configuration stackable Gigabit Ethernet switches that provide enterprise-level access to campus and branch applications.  They run on Cisco IOS software and support simple device management and network management.  The Cisco Catalyst 2960-X Series provides easy equipment, configuration, monitoring, and troubleshooting.  These fully managed switches can provide advanced Layer 2 and Layer 3 features, as well as optional Power over Ethernet (PoE+) power supplies.  They are designed to simplify operations to reduce total cost and achieve scalable, safe, and energy-saving business operations through intelligent services. These switches provide enhanced application visibility, network reliability, and network resilience.

(c1-c2960x-48td-l)Cisco ONE Catalyst 2960X-48TD-L -switch-48 ports-hosting-rack mountable-switching capacity: 216 Gbps ¦ forwarding performance (64-byte packet size): 130.

Main Features :

  • 48TD-L
  • Switch
  • managed
  • 48 x 10/100/1000 + 2 x 10 Gigabit SFP+
  • desktop
  • rack-mountable

Related Products

C1-C2960X-48TD-L Datasheet Specification

General
Device TypeSwitch – 48 ports – managed – stackable
Enclosure TypeDesktop, rack-mountable 1U
SubtypeGigabit Ethernet
Ports48 x 10/100/1000 + 2 x 10 Gigabit SFP+
PerformanceSwitching capacity: 216 Gbps ¦ Forwarding performance (64-byte packet size): 130.9 Mpps
CapacityActive VLANs: 1023
Jumbo Frame Support9216 bytes
Max Units In A Stack8
Remote Management ProtocolSNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, CLI
Authentication MethodKerberos, Secure Shell (SSH), RADIUS, TACACS+
FeaturesFull duplex capability, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, DiffServ support, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology, Unicast Reverse Path Forwarding (URPF), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Shaped Round Robin (SRR), LLDP support, DHCP relay, Link Aggregation Control Protocol (LACP), MAC Address Notification, Remote Switch Port Analyzer (RSPAN), Hot Standby Router Protocol (HSRP) support, Energy Efficient Ethernet, Management Information Base (MIB), Multicast VLAN Registration (MVR), Strict Priority Queuing (SPQ), Class of Service (CoS), Cisco FlexStack Plus, DiffServ Code Point (DSCP) support
Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1AX
ProcessorAPM86392: 600 MHz
RAM512 MB
Flash Memory128 MB
Status IndicatorsPort transmission speed, port duplex mode, system, status, link/activity
Expansion / Connectivity
Interfaces48 x 1000Base-T RJ-45 ¦ 1 x console RJ-45 ¦ 1 x mini-USB Type B management ¦ 1 x USB Type A ¦ 1 x 1000Base-TX RJ-45 management ¦ 2 x SFP+ uplink
Expansion Slots1 (total) / 1 (free) x Stacking Module slot
Power
Power DeviceInternal power supply
Power RedundancyOptional
Voltage RequiredAC 120/230 V (50/60 Hz)
Power Consumption Operational32.9 Watt
FeaturesRedundant Power System (RPS) connector
MTBF445,460 hours
Compliant StandardsCISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, UL 60950-1 Second Edition, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, VCCI Class A, KN24, KN22 Class A, EN 300386, RoHS 2011/65/EU
Miscellaneous
Software IncludedCisco IOS LAN Base
Width17.5 in
Depth11 in
Height1.8 in
Weight9.48 lbs
Software / System Requirements
Service & SupportLimited warranty – advance parts replacement – lifetime – response time: next business day ¦ Technical support – consulting – 90 days
Min Operating Temperature23 °F
Max Operating Temperature113 °F
Humidity Range Operating10 – 95% (non-condensing)
Min Storage Temperature-13 °F
Max Storage Temperature158 °F
Humidity Range Storage10 – 95% (non-condensing)
