AIR-SAP1602I-C-K9 Datasheet
AIR-SAP1602I-C-K9 Datasheet - Image 2
AIR-SAP1602I-C-K9 Datasheet - Image 3
AIR-SAP1602I-C-K9 Datasheet - Image 4
AIR-SAP1602I-C-K9 Datasheet - Image 5

AIR-SAP1602I-C-K9 Datasheet

$695.00 Original price was: $695.00.$292.00Current price is: $292.00.
In Stock

< tbody >

Model:AIR-SAP1602I-C-K9 Cisco Aironet 1600 Series Access Points
Detail:802.11a/g/n Stand-Alone AP, Int Ant, C Reg Domain Cisco Aironet 1600 Series Access Points

PDF Attachment: AIR-SAP1602I-C-K9 Datasheet

In Stock
  • Day and night customer service
Category:

Description

AIR-SAP1602I-C-K9 Datasheet Specification

Product DescriptionCisco Catalyst 1600 Series Access Points with Internal Antenna
Devide TypeWireless  Access point
Regulatory domainC regulatory domain
Software
  • Cisco Unified Wireless Network Software (available in Q4CY12)
  • Cisco IOS ® Software Release (available in Q4CY12)
Data rates supported
  • ● 802.11a: up to 54 Mbps
    ● 802.11g: up to 54 Mbps
  • ● 802.11n on 2.4 GHz: up to 300Mbps
Maximum number of nonoverlapping channels5 GHz
● 802.11a:
◦ 20 MHz: 24
● 802.11n:
◦ 20 MHz: 24
◦ 40 MHz:92.4 GHz
● 802.11b/g:
◦ 20 MHz: 3
● 802.11n:
◦ 20 MHz: 3
Antenna (purchase separately)
  • Certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz)
  • Cisco offers the industry’s broadest selection of 802.11n antennas delivering optimal coverage for a variety of deployment scenarios
Interfaces
  • 10/100/1000BASE-T autosensing (RJ-45)
  • Management console port (RJ-45)
System memory
  • 256 MB DRAM
  • 32 MB flash
Power consumption (power supply purchase separately) 15.4 Watts (Standard 802.3af POE)
IEEE standards
  • IEEE 802.11a/b/g, 802.11n, 802.11h, 802.11d
Security
  • ● 802.11i, Wi-Fi Protected Access 2 (WPA2), WPA
    ● 802.1X
  • ● Advanced Encryption Standards (AES), Temporal Key Integrity Protocol (TKIP)
Extensible Authentication Protocol (EAP) types
  • ● EAP-Transport Layer Security (TLS)
    ● EAP-Tunneled TLS (TTLS) or Microsoft Challenge Handshake Authentication Protocol Version 2 (MSCHAPv2)
    ● Protected EAP (PEAP) v0 or EAP-MSCHAPv2
  • ● EAP-Flexible Authentication via Secure Tunneling (FAST)
    ● PEAP v1 or EAP-Generic Token Card (GTC)
    ● EAP-Subscriber Identity Module (SIM)
Frequency band and 20-MHz operating channelsC Regulatory Domain:

– 2.412 to 2.472 GHz; 13 channels

– 5.745 to 5.825 GHz; 5 channels



Environmental
  • ● Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C)
    ● Nonoperating (storage) Altitude Test: -25˚C, 15,000 ft.
    ● Operating temperature: -4 to 122°F (-20 to 50°C)
  • ● Operating humidity: 10 to 90 % (noncondensing)
    ● Operating Altitude Test: -40˚C, 9843 ft.
